ซ็อกเก็ต ลวดสลิง Crosby Open Swage Sockets S-501

ซ็อกเก็ต ลวดสลิง Crosby Open Swage Sockets S-501

รายละเอียด และ ขนาด

• Forged from special bar quality carbon steel, suitable for cold forming.
• Swage Socket terminations have an efficiency rating of 100% based on the catalog strength of wire rope.
• Hardness controlled by spheroidize annealing.
• Stamp for identification after swaging without concern for fractures (as per directions in Wire Rope End Terminations User’s Manual).
• Swage sockets incorporate a reduced machined area of the shank which is equivalent to the proper “After Swage” dimension. Before swaging, this provides
  for an obvious visual difference in the shank diameter. After swaging, a uniform shank diameter is created allowing for a QUIC-CHECK® and permanent visual inspection opportunity.
  • Designed to quickly determine whether the socket has been through the
    swaging operation and assist in field inspections, it does not eliminate the
    need to perform standard production inspections which include gauging for
    the proper “After Swage” dimensions or proof loading.

Reference: Crosby S-501
